Stainless Steel:
- ASTM/ASME A/SA 182 F304 / F304L
- ASTM/ASME A/SA 182 F316 / F316L
Duplex & Super Duplex Steel:
- ASTM A182 F51, F53, F55, F44
High Performance Alloys:
- Alloy 400, 625, 800, 825
We supply a wide variety of flange types to meet diverse application needs:
- Weld Neck Flanges
- Blind Flanges
- Slip-On Flanges
- Socket Weld Flanges
- Threaded Flanges
- Orifice Flanges
- Spades, Spacers, and Spectacle Blinds
- API Flanges
Precision-Engineered Connections
for Pressure Piping Systems
Flanges serve as critical connection components in pipelines and associated equipment, allowing for secure assembly and easy disassembly. Commonly used in the oil, gas, and petrochemical industries, flanges typically feature bolt-hole patterns for fastening and gasket profiles for pressure-tight sealing. The design and specification of each flange are determined by the pressure rating, size, and service conditions of the system in which it’s installed.
Specifications & Industry Standards
Our flanges conform to the following international standards:
- ANSI B16.5
- ANSI B16.47 Series A & B (MSS SP-44)
- API 605 / API 6A / API 6BX
Material Grades Available:
Carbon & Low Temperature Steel:
- ASTM/ASME A/SA 105N
- ASTM/ASME A/SA 350 LF2 Class 1/2
- ASTM/ASME A/SA 694 F52, F60, F65, F70
- ASTM/ASME A/SA 516 Grade 65 / 70
From ⅛ inch to 48 inches, available in various pressure classes, material grades, and facing types.
• Flat Face (FF)
• Raised Face (RF)
• Ring Type Joint (RTJ)
• ANSI: Class 150, 300, 600, 900, 1500, 2500
• API: 3K to 15K
Every flange we supply is precision-manufactured and tested to meet the performance demands of high-pressure environments—ensuring secure, leak-free connections across critical systems.
